Application
• Automotive
◆ Cabin heating of electric vehicles
◆ Diesel fuel preheating
◆ Diesel fuel filter heating
◆ Heating of crank case venting system
◆ Windshield washer nozzle heating
• Domestic
◆ Bimetal heaters for door latches of washing machines
◆ Fan heaters
◆ Heaters for optical communication distributors
◆ Insecticide and perfume vaporizers
◆ Oil preheating in oil burners
◆ Thermal actuators for liquid dispensers and thermostats
◆ Heaters for medical appliances
• Others
◆ Lens heated
◆ Glue guns
◆ Plastic film welders
Features
◆ The temperature pulsation which is observed in the bimetallic thermostat application can be eliminated.
◆ The heater element itself functions as a temperature regualator.
◆ Compact and light design together with simple construction permits easy handing in wining, etc.
◆ Excellent lfe characteristics ensure a longer service life than Nickel-chrome heaters under normal operating conditions.
◆ No risk of fire
Structures and Dimensions
Electrical Specifications
◆ Heating elements for low voltage applications
| Order Number | Curie Temp. | Surface Temp. | Resistance At25℃ | Rated Voltage | Maximum Voltage | Dimensions |
| Tc(℃) | Ts(±10℃) | R25 (Ω) | Vr(V) | Vmax(V) | D/L(mm) | d/W(mm) | T(mm) |
| MZ4X1Φ190415-2R0□9/40 | 0 | 40 | 2.0 | 9 | 18 | Φ19.0 | Φ4.3 | 1.5 |
| MZ4P4S1210-9R0□V12/70 | 40 | 70 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4P6S1210-9R0□V12/80 | 60 | 80 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4P8S1210-9R0□V12/95 | 80 | 95 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4P9S0825-360□V24/115 | 90 | 115 | 36 | 24 | 30 | Φ8.5 | - | 2.5 |
| MZ4X0S0815-180□V24/120 | 100 | 120 | 18 | 24 | 30 | Φ8.0 | - | 1.5 |
| MZ4X1Φ160415□12/120 | 110 | 120 | 2.4 | 12 | 24 | Φ16.0 | Φ4.3 | 1.5 |
| MZ4X0S0815-100□V24/125 | 100 | 125 | 10 | 24 | 30 | Φ8.0 | - | 1.5 |
| MZ4X2S1210-9R0□V12/130 | 120 | 130 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4X3S1215-3R0□V12/140 | 130 | 140 | 3.00 | 12 | 14 | Φ12.0 | - | 1.5 |
| MZ4X3S1215-1R5□V12/145 | 135 | 145 | 1.55 | 13.5 | 28 | Φ12.0 | - | 1.5 |
| MZ4X5S1216-2R0□V13/160 | 150 | 160 | 2 | 13.5 | 28 | Φ12.0 | - | 1.6 |
| MZ4X5S1210-9R0□V12/165 | 155 | 165 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4X8S1210-9R0□V12/185 | 180 | 185 | 9 | 12 | 30 | Φ12.0 | - | 1 |
| MZ4X9S0820-100□V18/215 | 195 | 215 | 100 | 18 | 36 | Φ8.0 | - | 2 |
| MZ4Y4S1516-4R5□V13/250 | 240 | 250 | 4.5 | 13.5 | 24 | Φ14.7 | - | 1.65 |
| MZ4P8S350614-3R2□V12/110 | 80 | 110 | 3.2 | 12 | 20 | 35.0 | 6.2 | 1.4 |
| MZ4X3S221225-1R8□V14/145 | 135 | 145 | 1.88 | 14 | 18 | 22.0 | 12 | 2.5 |
| MZ4X3S341524-3R1□V24/145 | 135 | 145 | 3.13 | 24 | 36 | 34.0 | 15 | 2.4 |
| MZ4X2S350614-3R2□V12/145 | 120 | 145 | 3.2 | 12 | 20 | 35.0 | 6.2 | 1.4 |
| MZ4X4S281216-1R6□V14/150 | 140 | 150 | 1.65 | 13.5 | 28 | 28.0 | 12 | 1.65 |
| MZ4X4S360820-5R0□V24/150 | 140 | 150 | 5 | 24 | 36 | 36.0 | 8 | 2 |
| MZ4X5S300610-4R5□V14/160 | 150 | 160 | 4.5 | 13.5 | 24 | 30.0 | 5.8 | 1 |
| MZ4X5S160416-1R5□V12/165 | 155 | 165 | 1.5 | 12 | 24 | 16.5 | 4.5 | 1.65 |
| MZ4X6S341524-1R7□V12/170 | 160 | 170 | 1.7 | 12 | 24 | 34.0 | 15 | 2.4 |
| MZ4X6S300610-200□V48/170 | 160 | 170 | 20 | 48 | 60 | 30.0 | 5.8 | 1 |
| MZ4X7S300610-2R3□V12/180 | 170 | 180 | 2.35 | 12 | 24 | 30.0 | 5.8 | 1 |
| MZ4X7S300610-3R0□V12/180 | 170 | 180 | 3 | 12 | 24 | 30.0 | 5.8 | 1 |
| MZ4X6S350614-3R2□V12/180 | 160 | 180 | 3.2 | 12 | 20 | 35.0 | 6.2 | 1.4 |
| MZ4X8S350614-3R2□V12/200 | 180 | 200 | 3.2 | 12 | 20 | 35.0 | 6.2 | 1.4 |
| MZ4Y2S350614-6R4□V12/230 | 220 | 230 | 6.4 | 12 | 20 | 35.0 | 6.2 | 1.4 |
Notes:
1. □ is the resistance tolerance M:±20% X:±25% N:±30% S: Special
2. Vr can be selected at 1.5-68V.
3. Ts can be selected at 35-350℃.
4. Other type are available on request.
◆ Heating elements for high voltage applications
| Order Number | Curie Temp. | Surface Temp. | Resistance At25℃ | Rated Voltage | Maximum Voltage | Dimensions |
| Tc(℃) | Ts(±10℃) | R25 (Ω) | Vr(V) | Vmax(V) | D/L(mm) | W(mm) | T(mm) |
| MZ4P5S1220-122□V230/100 | 50 | 100 | 1200 | 230 | 270 | Φ11.8 | - | 2.0 |
| MZ4P9S1220-122□V230/125 | 90 | 125 | 1200 | 230 | 270 | Φ11.8 | - | 2.0 |
| MZ4X2S1325-102□V110/135 | 120 | 135 | 1000 | 110 | 140 | Φ13.0 | - | 2.5 |
| MZ4X1S0803-422□V230/135 | 110 | 135 | 4200 | 230 | 270 | Φ8.0 | - | 3 |
| MZ4X1S1220-122□V230/140 | 110 | 140 | 1200 | 230 | 270 | Φ11.8 | - | 2.0 |
| MZ4X3S1220-122□V230/160 | 130 | 160 | 1200 | 230 | 270 | Φ11.8 | - | 2.0 |
| MZ4X5S0803-422□V230/170 | 150 | 170 | 4200 | 230 | 270 | Φ8.0 | - | 3 |
| MZ4X5S1220-122□V230/180 | 150 | 180 | 1200 | 230 | 270 | Φ11.8 | - | 2.0 |
| MZ4X8S0803-422□V230/200 | 180 | 200 | 4200 | 230 | 270 | Φ8.0 | - | 3 |
| MZ4Y2S0803-602□V230/235 | 220 | 235 | 6000 | 230 | 270 | Φ8.0 | - | 3 |
| MZ4Y3S0803-102□V230/240 | 230 | 240 | 1000 | 230 | 270 | Φ8.0 | - | 3 |
| MZ4P5S350620-701□V230/100 | 50 | 100 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4P7S350620-701□V230/115 | 70 | 115 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4X1S350620-701□V230/145 | 110 | 145 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4X3S350620-701□V230/160 | 130 | 160 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4X6S241520-302□V220/170 | 160 | 170 | 3000 | 220 | 480 | 24.0 | 15 | 2 |
| MZ4X6S241524-152□V360/170 | 160 | 170 | 1500 | 360 | 420 | 24.0 | 15 | 2.4 |
| MZ4X5S350620-701□V230/180 | 150 | 180 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4X5S281221-302□V400/190 | 155 | 190 | 3000 | 400 | 600 | 28.8 | 12.4 | 2.1 |
| MZ4X8S350620-701□V230/205 | 180 | 205 | 700 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4X9S291021-402□V350/215 | 190 | 215 | 4000 | 350 | 800 | 28.8 | 9.8 | 2.1 |
| MZ4X9S393126-151□V600/220 | 195 | 220 | 150 | 600 | 750 | 39.2 | 30.8 | 2.6 |
| MZ4Y2S393119-871□V350/240 | 220 | 240 | 875 | 350 | 450 | 39.2 | 30.8 | 1.9 |
| MZ4Y2S393125-871□V540/240 | 220 | 240 | 875 | 540 | 600 | 39.2 | 30.8 | 2.5 |
| MZ4Y2S350620-102□V230/240 | 220 | 240 | 1000 | 230 | 270 | 35.0 | 6.2 | 2 |
| MZ4Y7S350620-132□V230/280 | 270 | 280 | 1300 | 230 | 270 | 35.0 | 6.2 | 2 |
Notes:
1.□ is the resistance tolerance M:±20% X:±25% N:±30% S: Special
2.Vr can be selected at 100-1000V.
3.Ts can be selected at 35-350℃.
4.Other type are available on request.
