    UL Lightweight PTC Type Thermistor For Optical Communication 485 Protection PTC Thermistor LKMZB-6 30-60Ω And LKMZB-10 3

    Ask Lasest Price
    Brand Name : linkun
    Model Number : PTC thermistor for protection ( Leaded Type)SPMZB-6 30-60Ω
    Certification : CE / ROHS / UL / TUV / SGS
    Price : Negotiation
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 24 million per year
    Delivery Time : Negotiation
    • Product Details
    • Company Profile

    UL Lightweight PTC Type Thermistor For Optical Communication 485 Protection PTC Thermistor LKMZB-6 30-60Ω And LKMZB-10 3

    PTC Type Thdrmistor For Surge Current Suppressin Self Protecting In Case Of Overload With No Risk Of Over-Heating


    Product Description​

    ◆ Self protecting in case of overload with no risk of over-heating
    ◆ Encased thermistor disk with clamp contacts for high reliability
    ◆ For high pulse currents and a high number of inrush-power cycles
    ◆ Can handle 2kv energy-limited peak voltage

    Application

    ◆ Automotive on-board charging
    ◆ Discharge - charge circuits
    ◆ Power inverters
    ◆ Server power surge protection
    ◆ Servo motor control
    ◆ Welding equipment
    Structures and Dimensions​

    Electrical Specifications

    Order NumberMax. Voltage
    Vmax(VAC)
    Max. Link Voltage
    VLmax(VDC)
    Resistance At 25°C
    R25(Ω)
    Curie Temp.
    TC (°C)
    Heat Capacity
    Cth(J/K)
    Thermal Cooling Time Constant
    τth (s)
    Dimensions(mm)
    DHT
    MZ21X209-700□B6#260370701200.4709.013.57.5
    MZ21X209-121□B6#2603701201200.6809.013.57.5
    MZ21X209-151□B6#2603701501200.6809.013.57.5
    MZ21X212-250□B8#28040025120110012.516.55
    MZ21X213-500□B8#280400501201.412013.018.07.5
    MZ21X213-800□B8#280400801201.412013.018.07.5
    MZ21X413-600□C5#350500601401.4510513.5177
    MZ21X315-560□D4#440620561302.110015.019.07.5
    MZ21X213-121□D4#4406201201201.412013.018.07.5
    MZ21X417-600□D4#440625601402.312017217.5
    MZ21X413-121□D4#4406251201401.4510513.5177
    MZ21X213-151□D4#4406201501201.412013.018.07.5
    MZ21X209-501□D4#4406205001200.6809.013.57.5
    MZ21X109-103□D4#44062011001150.6809.013.57.5
    MZ21X417-121□D6#4606501201402.312017217.5
    MZ21X315-120□D8#4806801201302.110015.019.07.5
    MZ21X413-251□D8#4806802501401.4510513.5177
    MZ21X113-501□E6#5608005001151.412013.018.07.5
    MZ21X413-501□E6#5608005001401.4510513.5177
    MZ21X417-251□F0#6008502501402.312017217.5
    MZ21X413-102□F0#60085010001401.4510513.5177
    MZ21X417-501□G0#70010005001402.312017217.5


    Note:

    1.is the resistance tolerance M:±20% X:±25% N:±30% S: Special
    2. is the internal control code
    3.The F value can be selected for 5mm, 7.5mm, 10mm
    4.The L value canbe selected for 3mm, 20mm, 25mm, 35mm
    5.The d value can be selected for 0.6mm, 0.8mm, 1.0mm
    6.Other type are available on request
